PROGRAM TYPE
* 입출력 절연 (Transformer Isolation)
* DIN RAIL Mounting TYPE
* MULTINPUT(mA, mV, V, PT100Ω, T/C)
* 1OUTPUT & 2OUTPUT 전송출력
* 1 & 2 ALARM 접점출력
* RS485 or RS422 출력
* FREE VOLTAGE(95V~250V AC) 또는 11~27V DC
* 고성능, 고정도의 변환기
* CONVERTER TYPE
- PLUG IN TYPE
- SMART TYPE
- ALARM SETTER TYPE
* SIZE
* 1POINT : 50W×85H×122D
* 2POINT : 34W×105H×100D
E-Catalog 관리자 -
WALL-MOUNTING TYPE
* 입출력 절연 (Transformer Isolation)
* WALL Mounting TYPE
* CE-MARK, EM-MARK 인증마크
* 2 OUTPURT & 4 OUTPUT 전송출력
* 2 & 4 ALARM 접점출력
* 과전압 보호 회로
* 고성능, 고정도의 변환기
* CONVERTER TYPE
- ISOLATOR
- DISTRIBUTOR
- R/I CONVERTER(RTD,POTENTIOMETER)
- PULSE CONVERTER
- ADDER/SUBTRACTOR
* SIZE
* 1POINT : 50W×85H×122D
* 2POINT : 65W×129H×138D
E-Catalog 관리자 -
PLUG-IN TYPE
* 입출력 절연 (Transformer Isolation)
* DIN RAIL Mounting TYPE (8PIN 11PIN)
* CE-MARK, EM-MARK 인증마크
* 1 OUTPUT & 2 OUTPUT 전송출력
* 과전압 보호 회로
* 고성능, 고정도의 변환기
* CONVERTER TYPE
- ISOLATOR
- DISTRIBUTOR
- R/I CONVERTER(RTD,POTENTIOMETER)
- PULSE CONVERTER
- ADDER/SUBTRACTOR
* SIZE
* 1POINT : 50W×85H×122D
* 2POINT : 50W×85H×133D
E-Catalog 관리자
-
CALIBRATOR
* PROGRAM TYPE
* WALL(SHN-3800) & PANEL(SHN-3700) MOUNTING TYPE
* MULTI(mA, mV, V, PT100Ω, T, C) INPUT
* ISOLATION OUTPUT(4-20mA)
* 2&4 ALRAM 접점출력
* AC 110V/220V POWER
* INPUT, SCALE, OUTPUT RANGE 설정가능
* 4 DIGIT 7SEGMENT INDICATING
* 고성능, 고정도의 지시계
* SIZE
- SHIN-3700(240W×96H×175D)
* CUTTING SIZE(236W×92H)
- SHIN-3800(330W×250H×92D)
E-Catalog 관리자 -
LARGE DISPLAY TYPE
* PROGRAM TYPE
* WALL(SHN-3800) & PANEL(SHN-3700) MOUNTING TYPE
* MULTI(mA, mV, V, PT100Ω, T, C) INPUT
* ISOLATION OUTPUT(4-20mA)
* 2&4 ALRAM 접점출력
* AC 110V/220V POWER
* INPUT, SCALE, OUTPUT RANGE 설정가능
* 4 DIGIT 7SEGMENT INDICATING
* 고성능, 고정도의 지시계
* SIZE
- SHIN-3700(240W×96H×175D)
* CUTTING SIZE(236W×92H)
- SHIN-3800(330W×250H×92D)
E-Catalog 관리자 -
BAR-GRAPHIC TYPE
* PROGRAM TYPE
* PANEL MOUNTING TYPE
* CE-MARKING 인증마크
* MULTI(mA, mV, V, PT100Ω, T, C) INPUT
* ISOLATION OUTPUT(4-20mA)
* 2&4 ALRAM 접점출력
* AC 110V/220V POWER
* INPUT, SCALE, OUTPUT RANGE 설정가능
* GREEN or RED 101-BAR CEL
* 4 DIGIT 7SEGMENT INDICATING
* 고성능, 고정도의 지시계
* SIZE : 36W×144H×169.5D
* CUTTING SIZE : 33W×141H
E-Catalog 관리자 -
MULTI INPUT PROGRAM TYPE
* PROGRAM TYPE
* PANEL MOUNTING TYPE
* CE-MARKING 인증마크
* MULTI(mA, mV, V, PT100Ω, T, C) INPUT
* ISOLATION OUTPUT (4-20mA, RS422/485)
* 2&4 ALRAM 접점출력
* AC 110V/220V POWER
* INPUT, SCALE, OUTPUT RANGE 설정 가능
* 4DIGIT 7SEGMENT DISPLAY
* 고성능, 고정도의 지시계
* SIZE : 48W×96H×112D
* CUTTING SIZE : 45W×92H
E-Catalog 관리자
-
TOTALIZER
* PROGRAM TYPE
PANEL MOUNTING TYPE
* CE-MARKING 인증마크
* mA, V, 2-WIRE INPUT
* ISOLATION OUTPUT(4-20mA, PULSE, RS422/485) 2 ALRAM 접점 출력
* AC 110V/220V POWER
* 순시값, TOTAL 적산, 일일적산 DISPLAY
* SCALE, OUTPUT RANGE 설정 가능
* 4DIGIT 7SEGMENT DUAL DISPLAY
* 고성능, 고정도의 지시계
* SIZE : 48W×96H×112D
* CUTTING SIZE : 45W×92H
E-Catalog 관리자
-
압력 Pressure(P701 Series)
Differential Pressure Transmitter
▷ 간략설명
★ Feature
· Measuring ranges from 0.001 to 3.5MPa
· Advanced piezoresistive silicon measuring cell
· Excellent accuracy and long term stability
★ Applications
The High precision differential pressure Transmitter can be used for a wide range of application in process control, automatic machinery and hydraulic or pneumaticequipments
· Chemical, petrochemical, food and drug process controls
· Hydraulic and pneumatic equipments
· Machine tools and automatic machinery
· LPG and LNG transmissioncontrol and storage tank monitoring
· Engine monitoring and control
· Vacuum pump and injection molding machine
· HVAC
E-Catalog 관리자 -
압력 Pressure(P900 Series)
Non Corrosive Gas Pressure Transmitter
▷ 간략설명
★ Feature
· Measuring ranges from 0.001~1MPa
· Advanced semiconductor sensor
· Excellent accuracy and long term stability
· 200% proof pressure
· DIN Rail mounted
★ Applications
The transmitters can be used for a wide range of applications in process control, automatic building control.
· HVAC System
· Pneumatic equipment
· Machine tools and automatic machinery
E-Catalog 관리자
